FEATURE:
|
|
|
Single
channel digital ECG machine with measurement
|
|
Simultaneously
12 leads acquisition
|
|
Multiple
operation mode (Manual/Auto/Ref.lead)
|
|
LCD
to display operation status
|
|
Built-in
standard RS232 Interface
|
|
DC/AC
power with built-in rechargeable Ni-MH battery
|
|
SPECIFICATION:
|
|
|
Lead
|
Standard
12 leads
|
|
Acquisition
|
Simultaneous
12 leads
|
|
Resolution
|
12bit/1000Hz
|
|
Operation
mode
|
Manual
mode , 3 Auto Modes (with measurement report )
|
|
Filter
|
AC
, EMG Filter
|
|
Drift
filter
|
Anti-drift
system
|
|
CMMR
|
>
60dB
|
|
|
>
100dB(with AC filter)
|
|
Input
circuit
|
Floating
Protection circuit against Defibrillator effect
|
|
Input
circuit current
|
<
0.1µA
|
|
Input
Impedance
|
>
50 M¦¸
|
|
Patient
current leakage
|
<
10µA
|
|
Calibrating
Voltage
|
1mV
+/- 3%
|
|
Time
constant
|
>
3.2 s
|
|
Frequency
response
|
0.05Hz~150Hz
|
|
Noise
level
|
<
15µVp-p
|
|
Threshold
|
<
20µV
|
|
Paper
speed
|
25,
50mm/s (+/- 3%)
|
|
Sensitivity
|
Auto
, 2.5,5,10,20mm/mV
|
|
Recorder
|
High
resolution thermal array printer
|
|
Paper
specification
|
50mm
x 30m roll
|
|
LCD
display
|
Display
menu, operation status and ECG waveform
|
|
Safety
level
|
GB9706.1-1995
class I , type CF
|
|
Power
supply
|
AC
220V/110V +/- 10% 50/60Hz +/- 1Hz 30VA
|
|
|
DC
14.4V-1500mAh rechargeable Ni-MH battery
|
|
Dimension
|
288
x 209 x 62mm
|
|
Dimension
(carton)
|
380
x 300 x 210mm
|
|
Net
Weight
|
3kgs
|
|
Weight
|
4.5kgs
|
|
Standard
Accessories:
|
|
|
Patient
Cable,Thermal Printing Paper, Limb Electrodes, Chest Electrodes,
Power Supply Cable,
|
|
Grounding
Wire
|
