| FEATURE: |
|
| Three
channel Interpretive ECG machine |
| Simultaneously
12 leads acquisition |
| 8
Patients save/copy/communication |
| Multiple
operation mode (Manual/Auto/Ref.lead) |
| Large
LCD to display 12 leads ECG waveform |
| Built-in
standard RS232 Interface (USB is optional) |
| DC/AC
power with built-in rechargeable lithium battery |
| SPECIFICATION: |
|
| Lead |
Standard 12
leads |
| Acquisition |
Simultaneous
12 leads |
| Resolution |
12bit/1000Hz |
| Operation
mode |
Manual mode ,
3 Auto Modes (with interpretive report) |
| Filter |
AC , EMG
Filter |
| Drift
filter |
Anti-drift
system |
| CMMR |
> 60dB |
| |
>
100dB(with AC filter) |
| Input
circuit |
Floating
Protection circuit against Defibrillator effect |
| Input
circuit current |
<
0.1µA |
| Input
Impedance |
> 50 M¦¸ |
| Patient
current leakage |
< 10µA |
| Calibrating
Voltage |
1mV
+/- 3% |
| Time
constant |
> 3.2 s |
| Frequency
response |
0.05Hz~150Hz |
| Noise
level |
< 15µVp-p |
| Threshold |
<
20µV |
| Paper
speed |
25, 50mm/s (+/-
3%) |
| Sensitivity |
Auto ,
2.5,5,10,20mm/mV |
| Recorder |
High
resolution thermal array printer |
| Paper
specification |
63mm
x 30m roll |
| LCD
display |
Display menu,
operation status and ECG waveform |
| Safety
level |
GB9706.1-1995
class I , type CF |
| Power
supply |
AC 220V/110V +/-
10% 50/60Hz +/- 1Hz 30VA |
| |
DC
14.4V-1200mAh rechargeable lithium battery |
| Dimension |
288 x 209 x
62mm |
| Dimension
(carton) |
380 x 300 x
210mm |
| Net
Weight |
3kgs |
| Weight |
4.5kgs |
| Standard
Accessories: |
|
| Patient
Cable, Thermal Printing Paper, Limb Electrodes, Chest Electrodes,
Power Supply Cable, |
| Grounding
Wire |
